10121505-320424DLF Connectors High Power Card Edge Connector 60POS HPCE Connector

  • 1
  • 2

Brand Name : Original Factory

Model Number : 10121505-320424DLF

Certification : Lead free / RoHS Compliant

Place of Origin : CN

MOQ : 10

Price : Contact for Sample

Payment Terms : T/T, L/C, Western Union

Delivery Time : 5-8 work days

Packaging Details : 60POS

Part Number : 10121505-320424DLF

Series : HPCE®

Number of Positions/Bay/Row : 18; 12

Number of Positions : 60 (24 + 36 Power)

Card Thickness : 0.062" (1.57mm)

Operating Temperature : -55°C ~ 105°C

Contact Now

10121505-320424DLF Connectors High Power Card Edge Connector 60POS HPCE Connector

Product Description Of 10121505-320424DLF

10121505-320424DLF High Power Card Edge (HPCE®) connector is a next generation power card edge connector for demanding applica-tions requiring high linear current density and low power loss. HPCE® is rated to 9A per power contact beam (with multiple power contacts fully energized) without exceeding a 30°C temperature rise in still air.


Specification Of 10121505-320424DLF

Part Number: 10121505-320424DLF
Product Category: Standard Card Edge Connectors
Headers
60 Position
2.54 mm
Press Fit
Vertical
Housing Material: Thermoplastic (TP)
Insulation Resistance: 500 MOhms, 5 GOhms
Maximum Operating Temperature: + 105 ℃
Minimum Operating Temperature: - 55 ℃
Voltage Rating: 17 V, 548 V


Features Of 10121505-320424DLF

Current rating to 9A/power contact beam (with multiple power contacts fully energized) without exceeding a 30°C temperature rise in still air
Low profile height (2.8mm for straddle mount; 7.50mm for right angle) maximizes airflow for effective system cooling
One-piece assembly enables cost-effective power delivery for 1U and 2U power supplies or power distribution applications
Highly vented housing design maximizes heat dissipation
Vertical, right angle and straddle mount options are available with both power contacts for power distribution and signal contacts for power control
Number and placement of power and signal contacts are highly configurable for custom power needs
Polarized housing option ensures proper mating board orientation
Plastic housing features and mounting ear options are available for polarization to the host PCB as well as to secure the connector during the wave solder process


Applications Of 10121505-320424DLF

AC/DC pluggable power supplies in data, telecom and datacom/networking equipment
Industrial PCs
Industrial controls and instrumentation
Medical


Package Photo Of 10121505-320424DLF

10121505-320424DLF Connectors High Power Card Edge Connector 60POS HPCE Connector

Other Electronic Components In Stock

Part Number Package
STM32WB55REV7 68-VFQFPN
STM32WB55VCQ7 129-UFBGA
STM32WB55VEQ7 129-UFBGA
STM32WB55CGU7 48-UFQFN
STM32WLE5CCU7 48-UFQFN
BLUENRG-332AT 32-QFN
STM32WB1MMCH6 77-LGA
BLUENRG-232N 32-QFN
BLUENRG-332VC 36-WLCSP
BLUENRG-332AC 32-QFN
BLUENRG-332VT 36-WLCSP
STM32WL54CCU6 48-UFQFN
STM32WL54CCU7 48-UFQFN
STM32WLE5UCY7 59-WLCSP
STM32WL54JCI6 73-UFBGA
STM32WLE5JCI7 73-UFBGA
STM32WB55VGQ7 129-UFBGA
STM32WL54JCI7 73-UFBGA
STM32WL55UCY7 59-WLCSP
DA14531-00000FX2 24-FCGQFN
DA14531-00000OG2 17-WLCSP
DA14683-00000A92 60-VQFN
DA16200-00000F22 FCCSP-72
DA14683-00000U22 53-WLCSP
DA14586-00F02AT2 40-QFN
DA16200-00000A32 QFN-48
DA14697-00000HR2 100-VFBGA
DA14530-00000FX2 24-FCGQFN
DA14691-00000HQ2 86-VFBGA
DA14585-00000VV2 34-WLCSP
